Produkt przeznaczony wyłącznie do zastosowań profesjonalnych| Model | Dostępność | Gwarancja | Schowek | Twoja cena | Twoja cena | Ilość produktów Dodaj |
|---|---|---|---|---|---|---|
| AB7665 Modbus TCP Slave - J1939 | Na zamówienie | Gwarancja: | 3 365,00 zł 4 138,95 zł | Zaloguj się, aby poznać swoją cenę |
This Anybus X-gateway provides connectivity between Ethernet/IP and a J1939 Heavy Duty vehicle (CAN) network. The X-gateway appear as an Ethernet/IP slave/adapter allowing an Ethernet/IP master/scanner to read or write data from the J1939 network. HMS provides the X-gateway with a free Windows based configuration tool (BWConfig). This PC based software allows the user to map J1939 parameter (PGN) data into a range of memory addressable through the X-gateway Ethernet/IP interface.
Configuration of the X-gateway is simple using BWConfig and consists of setting up an I/O table containing selected J1939 PGNs and the rate that each will be read or written from the J1939 network. BWConfig will then automatically map the I/O table to a range of addresses accessible from the X-gateway Ethernet/IP interface. The configuration is downloaded from the PC to the X-gateway via an RS232 connection and is saved in FLASH memory.
Target Industries: * Electric Power Generation * Oil & Gas * Marine * Defense * Heavy Duty, Construction & Agricultural Vehicles * Testing & Validation * Any Diesel Engine based system supporting J1939
| Size: | 126 mm x 110 mm x 42 mm |
| Power Supply: | 12-30 VDC |
| Temperature: | 0-65°C |
| Current Consump: | Max 300 mA |
| Baud Rate: | 10/100 Mbit autodetect on Ethernet/IP |
| Mech Rating: | IP20 / Nema 1 |
| Profile Support: | SAE J1939 (CAN) |
| Config Method: | BW Config (free) |
| Appl Interface: | CAN and Ethernet (twisted pair) |
| Ethernet connector: | RJ45 |
| Config connector: | 9-pole DSUB |
| UL certification: | E203225, Listed 67AM, UL-1604 Class 1, Div 2, GP A, B, C, D, Temp Code T4 |
| ATEX certification: | ATEX 135419, II 3 G, EEx nL IIC T4, DEMKO 03 |
| Power supply connect: | 2-pole 5.08 mm Phoenix pluggable screw connector |
| CAN J1939 connector: | 5-pole 5.08 mm Phoenix pluggable screw connector |
| Price Group: | A |
| Order Code: | -AB7665 |
